What if, instead of using tonnes of metal to accelerate electrons, they were to “surf” on a wave of charge displacements in a plasma? This question, posed in 1979 by Toshiki Tajima and John Dawson, planted the seed for plasma wakefield acceleration (PWA). Scientists at DESY now report some of the first signs that PWA is ready to compete with traditional accelerators at low energies. The results tackle two of the biggest challenges in PWA: beam quality and bunch rate.
“We have made great progress in the field of plasma acceleration,” says Andreas Maier, DESY’s lead scientist for plasma acceleration, “but this is an endeavour that has only just started, and we still have a bit of homework to do to get the system integrated with the injector complexes of a synchrotron, which is our final goal.”
Riding a wave
PWA has the potential to radically miniaturise particle accelerators. Plasma waves are generated when a laser pulse or particle beam ploughs through a millimetres-long hydrogen-filled capillary, displacing electrons and creating a wake of alternating positive and negative charge regions behind it. The process is akin to flotsam and jetsam being accelerated in the wake of a speedboat, and the plasma “wakefields” can be thousands of times stronger than the electric fields in conventional accelerators, allowing particles to gain hundreds of MeV in just a few millimetres. But beam quality and intensity are significant challenges in such narrow confines.
In a first study, a team from the LUX experiment at DESY and the University of Hamburg demonstrated, for the first time, a two-stage correction system to dramatically reduce the energy spread of accelerated electron beams. The first stage stretches the longitudinal extent of the beam from a few femtoseconds to several picoseconds using a series of four zigzagging bending magnets called a magnetic chicane. Next, a radio-frequency cavity reduces the energy variation to below 0.1%, bringing the beam quality in line with conventional accelerators.
“We basically trade beam current for energy stability,” explains Paul Winkler, lead author of a recent publication on active energy compression. “But for the intended application of a synchrotron injector, we would need to stretch the electron bunches anyway. As a result, we achieved performance levels so far only associated with conventional accelerators.”
But producing high-quality beams is only half the battle. To make laser-driven PWA a practical proposition, bunches must be accelerated not just once a second, like at LUX, but hundreds or thousands of times per second. This has now been demonstrated by KALDERA, DESY’s new high-power laser system (see “Beam quality and bunch rate” image).
“Already, on the first try, we were able to accelerate 100 electron bunches per second,” says principal investigator Manuel Kirchen, who emphasises the complementarity of the two advances. The team now plans to scale up the energy and deploy “active stabilisation” to improve beam quality. “The next major goal is to demonstrate that we can continuously run the plasma accelerators with high stability,” he says.
With the exception of CERN’s AWAKE experiment (CERN Courier May/June 2024 p25), almost all plasma-wakefield accelerators are designed with medical or industrial applications in mind. Medical applications are particularly promising as they require lower beam energies and place less demanding constraints on beam quality. Advances such as those reported by LUX and KALDERA raise confidence in this new technology and could eventually open the door to cheaper and more portable X-ray equipment, allowing medical imaging and cancer therapy to take place in university labs and hospitals.
Further reading
P Winkler et al. 2025 Nature 640 907.
